Pricing

HUMMINGBIRD HELICOPTER PURCHASING PROGRAM

To place your order for the Hummingbird helicopter, please call 407-322-9488. A purchase agreement will be completed for you to sign. A deposit is required to secure all orders. No delivery position can be reserved without receipt of deposit.

Upon receipt of your deposit, Vertical Aviation Technologies, Inc. will immediately send a return receipt and list the earliest scheduled delivery date available. Please call during normal business hours to discuss any options or questions you may have regarding the kit and its delivery.

STANDARD KIT PRICING INFORMATION

The Following Items are included:

All Documentation - Instruction manual, drawings, photographs, illustrated parts manuals, maintenance and flight manuals.

Lower Cabin/Airframe - Preformed bulkheads/ribs, pilot drilled skins, castings, and hardware.

Upper Cabin/Airframe - Preformed ribs/firewall assembled with skins and hardware. Hard points and skins preassembled and riveted in place.

Landing Gear - Main and nose wheel/brake assemblies, oleo struts front and rear, 4130 chrome-molly steel weld assemblies, all castings and hardware.

Nose and Windshield - Windshield and composite nose chin windows, preformed ribs/bulkheads, instrument panel section, composite doors, and hardware.

Tail Cone - Tail cone, 4130 chrome-molly steel tail cone support, castings, stabilizers, and hardware.

Tail Rotor - Tail gearbox, Intermediate gearbox, pylon casting and tube, tail blades preassembled to hub painted and balanced, drive shaft, spline couplings, tail skid, control rods, and hardware.

Main Rotor - Main rotor head, 4130 chrome-molly steel pylon, main shaft, castings, bearings, swash plate components, preassembled main gearbox, tail drive shaft with bearings, support brackets, spline couplings and hardware.

Flight Control - Dual cyclic, dual collective, and dual pedal controls, mixing unit, tail cables, vibration dampers, brake cylinders and lines, control rods, rotor brake, electric trim, and hardware.


Powerplant/Clutch - 4130 chrome-molly steel engine mount, elastomeric lord mount, engine cooling fan, cylinder baffles, cylinder jacket, oil cooler and composite adaptors, oil tank and mounts, dual exhaust with mufflers, driveshafting, flywheel, clutch and freewheel unit, air filter, electric fuel pump, Teflon fuel hoses and fittings, oil hoses and fittings, plane power lightweight.  Everything required to install the IO-540 powerplant.


Fuel System - 57 gallon aircraft bladder tank, gaskets, filler neck, covers, fuel quantity probe, sump assembly, fuel strainer, and hardware.

Instruments and Electrical - Switches, circuit breakers, wire harness, connectors, relays, navigation lights, quadrant, cables, and hardware. Instruments Cylinder Head Temp, Engine Oil Temp, Fuel Press, Transmission Oil Press, Engine Oil Pressure, Fuel Qty, Manifold Pressure, Transmission Oil Temp, Airspeed, AMP/Volt Meter with Shunt, Magneto Pickup for Bendix Magnetos, Inverter, EL Light Bezels, Tach Generator, Dual Elect Tach, Tachogenerator Emulator, full night lighting

Seat - Composite seats and hardware.

Cowling - Composite engine cowling, upper section, ribs, brackets and hardware.

Main Rotor Blades - Blades preassembled.

TOTAL: $159,000.00



We are now offering a five stage purchase program broken down into five sections as follows:

FIVE GROUP PRICING INFORMATION

GROUP I . . . . . . . . . . . . . . . . . . . . . . $28,750.00

All Documentation – instruction manual, drawings, photographs, illustrated parts manuals,        maintenance and flight manuals.

Lower Cabin/Airframe – preformed bulkheads/ribs, pilot drilled skins, castings, and hardware.

Upper Cabin/Airframe - preformed ribs/firewall assembled with skins and hardware. Hardpoints and skins preassembled and riveted in place.

Landing Gear main and nose wheel/brake assemblies, oleo struts; front and rear, 4130 chrome-molly steel weld assemblies, all castings and hardware.

Nose and Windshield windshield and composite nose, preformed ribs/bulkheads, instrument panel section, composite doors and hardware.

Tail Cone tail cone, 4130 chrome-molly steel tail cone support, castings, stabilizers and hardware.

GROUP II . . . . . . . . . . . . . . . . . . . . . $57,800.00

Tail Rotor tail gearbox, and intermediate gearbox components, pylon casting and tube, carbon fiber tail rotor blades preassembled to hub, painted and balanced, driveshaft, spline couplings, tail skid, control rods and hardware.

Main Rotor – main rotor head components, 4130 chrome-molly steel pylon, main shaft, castings, bearings, swash plate components, preassembled main gearbox, tail driveshaft with bearings, support brackets, and hardware.

GROUP III . . . . . . . . . . . . . . . . . . . . . $19,280.00

Flight Control – dual cyclic, dual collective, and dual pedal controls, mixing unit, tail cables, heel rests, vibration dampers, brake cylinders and lines, control rods, rotorbrake, electric trim, magnetic brake, and hardware.

Fuel System – 57 gallon aircraft bladder tank, gaskets, filler neck, covers, fuel quantity probe, sump assembly, electric fuel pump, fuel and oil hoses, fuel strainer, fuel primer, and hardware.

GROUP IV . . . . . . . . . . . . . . . . . . . . .  $17,650.00

Powerplant/Clutch 4130 chrome-molly steel engine mount, elastomeric lord mount, engine cooling fan, cylinder baffles, cylinder jacket, oil cooler and composite adaptors, oil tank and mounts, dual exhaust with mufflers, driveshafting, flywheel, clutch and freewheel unit, air filter, electric fuel pump, Teflon fuel hoses and fittings, oil hoses and fittings, plane power lightweight alternator.  Everything required to install the IO-540 powerplant.

Instruments and Electrical  Switches, circuit breakers, wire harness, connectors, relays, navigation lights, quadrant, cables, and hardware.  Instruments Cylinder Head Temp, Engine Oil Temp, Fuel Press, Transmission Oil Press, Engine Oil Pressure, Fuel Qty, Manifold Pressure, Transmission Oil Temp, Airspeed, AMP/Volt Meter with Shunt, Magneto Pickup for Bendix Magnetos, Inverter, EL Light Bezels, Tach Generator, Dual Elect Tach, Tachogenerator Emulator, full night lighting.

GROUP V . . . . . . . . . . . . . . . . . . . . .  $35,520.00

Seat – composite front seats and hardware.

Cowling – composite engine cowling, upper center section, ribs, brackets and hardware.

Main Rotor Blades – blades preassembled.

TOTAL FOR ALL FIVE GROUPS  . . . . . . . . . . . . . . . . . . . . . . . $159,000.00

The following items are not included: engine, paint, upholstery, battery, crating and freight.

See the Options page for more details.
